7" HDMI Monitor with capacitive touch function - 779GL-70NP/C/T

capacitive touch monitor
  • capacitive touch monitor
  • HDMI monitor
  • VGA monitor
  • LCD MONITOR
  • Vehicle monitor
Model No.︰779GL-70NP/C/T
Brand Name︰LILLIPUT
Country of Origin︰China
Share on:

 Total 19 Related Items
Prev1011121314Next

Specifications︰Display Screen 7" LED backlit, 16:9
Resolution 800 x 480, 8bit, suport up to 1920 x 1080
Touch Panel: Capacitive Touch (optional)
Contrast Ratio: 500:1
Brightness: 1000cd/㎡
Viewing Angle: 140°/120°(H/V)
Input Signal: HDMI, VGA, AV, DVI(optional)
I/O port 1
Speaker 1
Input Voltage DC 7-36V
Battery External (optional)
Current 450mA
Power Consumption ≤4.5W
Audio Output ≤1W
Operating Temperature -20℃~60℃
Storage Temperature -30℃~70℃
Dimension(LWD) 185×118.5×29.5 mm
Weight 415g

Accessories:
589 Bracket
8 Keys remote control
VGA cable for touch
HDMI connect HDMI cable with touch
Composite cable
12V DC adapter
Manual
HDMI to DVI cable with touch (optional)
HDMI A/A cable with touch (optional)
VESA folding bracket(optional)
Car power cord (optional)
VESA battery bracket(optional)
Battery Plate(optional)
Advantages︰Multi-touch capacitive screen,
Lux auto brightness,
Integrated dustproof front panel,
I/O control interface,
HDMI, DVI, VGA & AV inputs,
High contrast: 500:1,
High brightness: 400cd/m².

Features:
10-point touch capacitive screen(OS: Windows 7 or above).
Lux auto brightness,
Integrated dustproof front panel,
I/O control interface,
High contrast: 500:1,
High brightness: 400cd/m².

Capacitive Touch Panel (779-70NP/C/T only)
Support 10-point allows people flip and zoom in/out picture via fingers, High precision fast response, and have a longer life, Better transmittance.

zoom out zoom in
Lux Auto Brightness (optional)
A light sensor designed to detect ambient lighting conditions adjusts the panel's brightness automatically, which makes viewing more conveniently & saves more power.

under hard light under weak light
I/O control interface
The interface has functions such as connecting with reverse trigger line in car reversing system, and control computer host to switch on/off, etc. Functions also can be customized to meet different demands.

car reversing trigger reversing image
Export Markets︰Worldwide
Payment Details︰Western Union/ T/T payment in advance
Ship Date︰within 7 days after order
Product Image

capacitive touch monitor
capacitive touch monitor

HDMI monitor
HDMI monitor

VGA monitor
VGA monitor

LCD MONITOR
LCD MONITOR

Vehicle monitor
Vehicle monitor
