| Specifications︰ | Display Screen 7" LED backlit, 16:9
Resolution 800 x 480, 8bit, suport up to 1920 x 1080
Touch Panel: Capacitive Touch (optional)
Contrast Ratio: 500:1
Brightness: 1000cd/㎡
Viewing Angle: 140°/120°(H/V)
Input Signal: HDMI, VGA, AV, DVI(optional)
I/O port 1
Speaker 1
Input Voltage DC 7-36V
Battery External (optional)
Current 450mA
Power Consumption ≤4.5W
Audio Output ≤1W
Operating Temperature -20℃~60℃
Storage Temperature -30℃~70℃
Dimension(LWD) 185×118.5×29.5 mm
Weight 415g
Accessories:
589 Bracket
8 Keys remote control
VGA cable for touch
HDMI connect HDMI cable with touch
Composite cable
12V DC adapter
Manual
HDMI to DVI cable with touch (optional)
HDMI A/A cable with touch (optional)
VESA folding bracket(optional)
Car power cord (optional)
VESA battery bracket(optional)
Battery Plate(optional) |
| Advantages︰ | Multi-touch capacitive screen,
Lux auto brightness,
Integrated dustproof front panel,
I/O control interface,
HDMI, DVI, VGA & AV inputs,
High contrast: 500:1,
High brightness: 400cd/m².
Features:
10-point touch capacitive screen(OS: Windows 7 or above).
Lux auto brightness,
Integrated dustproof front panel,
I/O control interface,
High contrast: 500:1,
High brightness: 400cd/m².
Capacitive Touch Panel (779-70NP/C/T only)
Support 10-point allows people flip and zoom in/out picture via fingers, High precision fast response, and have a longer life, Better transmittance.
zoom out zoom in
Lux Auto Brightness (optional)
A light sensor designed to detect ambient lighting conditions adjusts the panel's brightness automatically, which makes viewing more conveniently & saves more power.
under hard light under weak light
I/O control interface
The interface has functions such as connecting with reverse trigger line in car reversing system, and control computer host to switch on/off, etc. Functions also can be customized to meet different demands.
car reversing trigger reversing image |
| Export Markets︰ | Worldwide |
| Payment Details︰ | Western Union/ T/T payment in advance |
| Ship Date︰ | within 7 days after order |
|
|
Product Image
|
|
